Request Triggers

A Request trigger lets your application start one specific workflow for a connected user and, if you want, wait for the workflow's answer. Where an App Event fans out to every subscribed workflow and returns nothing, a request addresses a single workflow by its uuid and returns what that workflow produces.

Key Features

Setting up the workflow

1. Open the workflow in the editor.
2. Add the Request trigger and pick one of its two operations:
   • Await Workflow and Respond - the caller waits for the workflow to finish. Set Timeout (ms) to limit the wait.
   • Auto Respond with HTTP 200 Status - the caller gets 200 with no body right away. Nothing is returned from the workflow.
3. To control the response, end the workflow with the Webhook component's Response to Webhook Request action. It sets the Response Type (JSON, Raw, Binary, Redirect or No Data), the Status Code, the Headers and the Body.
4. Save and publish.

The trigger's output gives the workflow the incoming request: body, method, headers and parameters (the query string). The body is parsed by content type: JSON, XML, form data and multipart forms become structured data, other application/* types arrive as a file, and anything else arrives as text.

Calling the workflow

From your frontend

POST with the end user's JWT. The connected user is the JWT's sub claim.

const response = await fetch(`${baseUrl}/api/embedded/v1/workflows/${workflowUuid}`, {
    method: 'POST',
    headers: {
        Authorization: `Bearer ${jwtToken}`,
        'Content-Type': 'application/json',
        'X-Environment': 'PRODUCTION',
    },
    body: JSON.stringify({orderId: '1234'}),
});

const result = await response.json();

This route accepts only a JWT. It allows cross-origin requests, so you can call it straight from the browser.

From your backend

POST with your API Key and name the connected user in the path:

curl -X POST "https://your-bytechef-host.example.com/api/embedded/v1/$EXTERNAL_USER_ID/workflows/$WORKFLOW_UUID" \
  -H "Authorization: Bearer $API_KEY" \
  -H "Content-Type: application/json" \
  -H "X-Environment: PRODUCTION" \
  -d '{"orderId": "1234"}'

Both routes run the same workflow. X-Environment is optional and case-insensitive (DEVELOPMENT, STAGING, PRODUCTION). Without it, the call runs in PRODUCTION.

Which workflow runs

The workflowUuid is resolved against the connected user in this order:

1. An integration workflow. If the uuid belongs to an integration workflow, the call runs it through the connected user's instance of that integration.
2. The connected user's own automation copy. A uuid of a workflow the user copied from an automation template runs that copy.
3. A catalog reference. A catalog workflow uuid the user holds a reference to runs the catalog project's last published version of that workflow, with the user's own connections.
4. A copy of a catalog template. A catalog template uuid the user has already copied runs the user's copy.

The call never adds a workflow for the user. A catalog uuid the user has no reference to and no copy of returns 404. Add the workflow first, through the Automation Hub or the copy and provision endpoints described in Automation Code Workflows.

The response

With Await Workflow and Respond:

• If the workflow runs a Response to Webhook Request action, the HTTP response uses that action's status code, headers and body. A Redirect response is followed only for a relative path or the same host. Any other URL returns 400.
• Otherwise the response is 200 with the workflow's outputs as JSON.

The wait is capped at 5 minutes. A Timeout (ms) above that, or no timeout at all, waits 5 minutes. If the workflow does not finish in time, the run is marked failed and the call returns an error.

With Auto Respond with HTTP 200 Status, the response is always 200 with no body. Check the run in Workflow Executions.

Errors
